NCV5661MN12T2G Integrated Circuit Chip High Performance LDO Linear Voltage Regulator

NCV5661MN12T2G Integrated Circuit Chip High Performance LDO Linear Voltage Regulator

Proeuct Description Of NCV5661MN12T2G
NCV5661MN12T2G is a high performance, low dropout (LDO) linear voltage regulator designed for high power applications that require up to 1.0 A current. It is offered in both fixed and adjustable output versions. With output voltages as low as 0.9 V and ultra-fast response times for load transients, the NCV5661MN12T2G also provides additional features such as Enable and Error Flag (for the fixed output version), increasing the utility of this device. A thermally robust, 5 pin DPAK or DFN 3.0 x 3.3 mm, combined with an architecture that offers low ground current (independent of load), provides for a superior high-current LDO solution.

Specifications Of NCV5661MN12T2G

Features Of NCV5661MN12T2G
Ultra-Fast Transient Response (Settling Time: 1-3 µs
Low Noise Without Bypass Capacitor (26 µVrms)
Low Ground Current Independent of Load(3.0 mA Maximum)
Fixed/Adjustable Output Versions
Enable Function
Error Flag (Fixed Output Version)
Current Limit Protection
Thermal Protection
0.9 V Reference Voltage for Ultra-Low Output Operation
Power Supply Rejection Ratio > 65 dB

Applications Of NCV5661MN12T2G

Servers
Networking Equipment
Automotive
