LT6700CS6-1 Integrated Circuit Chip Micropower Low Voltage Dual Comparator With 400mV Reference

LT6700CS6-1 Integrated Circuit Chip Micropower Low Voltage Dual Comparator With 400mV Reference

Product Description Of LT6700CS6-1

LT6700CS6-1 combine two micropower, low voltage comparators with a 400mV reference in a 6-lead SOT-23 or tiny DFN package. Operating with supplies from 1.4V up to 18V, these devices draw only 6.5μA, making them ideal for low voltage system monitoring. Hysteresis is included in the comparators, easing design requirements to insure stable output operation.

Specification Of LT6700CS6-1

Features Of LT6700CS6-1

• Internal 400mV Reference

• Total Threshold Error: ±1.25% Max at 25°C

• Inputs and Outputs Operate to 36V

• Wide Supply Range: 1.4V to 18V

• Specified for –55°C to 125°C Temperature Range

• Low Quiescent Current: 6.5μA Typ at 5V

• Internal Hysteresis: 6.5mV Typ

• Low Input Bias Current: ±10nA Max

• Over-The-Top® Input also Includes Ground

• Open-Collector Outputs Allow Level Translation

• Available in Low Profile (1mm) SOT-23 (ThinSOT™) and 2mm × 3mm DFN Packages

• AEC-Q100 Qualified for Automotive Applications

Applications Of LT6700CS6-1

• Battery-Powered System Monitoring

• Threshold Detectors

• Window Comparators

• Relay Driving

• Industrial Control Systems

• Handheld Instruments

• Automotive Monitor and Controls
